APPENDIX B - PROGRAMMABLE SETPOINT VALUES
TABLE 13 - PROGRAMMABLE SETPOINT VALUES (CONT'D)
COMPRESSOR SCREEN
SETPOINT
Vent Line Off State
HOT GAS BYPASS SCREEN (COMPRESSOR SUBSCREEN)
SETPOINT
Close Percentage
Hold Period
Surge Sensitivity
Minimum Load
VSD CALIBRATION SCREEN (COMPRESSOR SUBSCREEN)
SETPOINT
Increment Amount
SURGE PROTECTION SCREEN (COMPRESSOR SUBSCREEN)
SETPOINT
Shutdown
Extended Run
Count Window
Count Limit
Surge Sensitivity
OIL SUMP SCREEN
SETPOINT
Manual Pump
Low Pressure Limit
Prelube Time
Coastdown Time
Heater Setpoint
ELECTROMECHANICAL STARTER SCREEN
SETPOINT
Local Motor Current Limit
Pulldown Demand Limit
Pulldown Demand Time
134
ACCESS MINIMUM
LEVEL VALUE
Service De-Energized
ACCESS MINIMUM
LEVEL VALUE
Service 5 %
Service 30 Min
Service 0.1
Service 0 °F
ACCESS MINIMUM
LEVEL VALUE
Service 0.1 Hz
ACCESS MINIMUM
LEVEL VALUE
Service Disabled
Service Disabled
Service 1 Min
Service 4
Service 0.3
ACCESS MINIMUM
LEVEL VALUE
Operator Disabled
Service 10 PSID
Service 15 Seconds
Service 150 Seconds
Service 125 °F
ACCESS MINIMUM
LEVEL VALUE
Operator 30 %
Operator 30 %
Operator 0 Min
FORM 160.10-O1
ISSUE DATE: 4/27/2018
MAXIMUM
DEFAULT
VALUE
Energized De-Energized
MAXIMUM
DEFAULT
VALUE
15 % 5 %
120 Min 30 Min
1.3 0.3
4 °F 0°F
MAXIMUM
DEFAULT
VALUE
10.0 Hz 1 Hz
MAXIMUM
DEFAULT
VALUE
Enabled Enabled
Enabled Disabled
5 Min 3 Min
20 15
1.3 0.3
MAXIMUM
DEFAULT
VALUE
Enabled Disabled
40 PSID 25 PSID
60 Seconds 30 Seconds
600 Seconds 150 Seconds
155 °F 140 °F
MAXIMUM
DEFAULT
VALUE
100 % 100 %
100 % 100 %
255 Min 0 Min
