Johnson Controls YORK OPTIVIEW CONTROL CENTER Operation Manual page 138

APPENDIX B - PROGRAMMABLE SETPOINT VALUES
TABLE 13 - PROGRAMMABLE SETPOINT VALUES (CONT'D)
PRINTER SCREEN (SETUP SUBSCREEN)
SETPOINT
Log Start Time
Output Interval
Automatic Printer Logging
ACC Auto Map Print
Printer Type
Print Report
OPERATIONS SCREEN (SETUP SUBSCREEN)
SETPOINT
Control Source
Number Of Starts
Operating Hours
Hot Gas (Bypass)
(Refrigerant) Level Control
Chiller Model
Refrigerant
HISTORY SCREEN
SETPOINT
Select Fault
CUSTOM VIEW SETUP SCREEN (CUSTOM VIEW SUBSCREEN)
SETPOINT
Custom Slot (1 through 10)
TREND SETUP SCREEN (TREND SUBSCREEN)
SETPOINT
Chart Type
Collection Interval
Data Point Slot # (1 through 6)
Data Point Min (1 through 6)
Data Point Max (1 through 6)
138
ACCESS MINIMUM
LEVEL VALUE
12:00 AM or
Operator
00:00
Operator 1 Min
Operator Disabled
Operator Disabled
Operator Okidata, WeighTronix, Epson, Seiko
Status, Setpoint, Schedule, Sales
View Order, Slot List, Custom Screen
ACCESS MINIMUM
LEVEL VALUE
Operator Local, ISN, Analog, Digital, Modem
Admin 0
Admin 0 Hours
Service Disabled
Service Disabled
Service CVHA, CHVB, CVHE, CVHF
Service R11
ACCESS MINIMUM
LEVEL VALUE
View Normal, Running, Fault #
ACCESS MINIMUM
LEVEL VALUE
Operator 0
ACCESS MINIMUM
LEVEL VALUE
Operator Continuous
Operator 1 Second
Operator 0
Operator Varies with each slot number programmed
Operator Varies with each slot number programmed
FORM 160.10-O1
ISSUE DATE: 4/27/2018
MAXIMUM
DEFAULT
VALUE
11:59 PM or 12:00 AM or
23:59
1440 Min 60 Min
Enabled Disabled
Enabled Disabled
Okidata
Status
Data
MAXIMUM
DEFAULT
VALUE
99999
876600 Hours 0 Hours
Enabled Disabled
Enabled Disabled
CVHA
R123
MAXIMUM
DEFAULT
VALUE
Normal
MAXIMUM
DEFAULT
VALUE
65535
MAXIMUM
DEFAULT
VALUE
One Screen Continuous
3600 Seconds 60 Seconds
65535
JOHNSON CONTROLS
00:00
Local
0
R11
0
0
