TABLE 13 - PROGRAMMABLE SETPOINT VALUES (CONT'D)
(MOD "B") SOLID STATE STARTER SCREEN
SETPOINT
Local Motor Current Limit
Pulldown Demand Limit
Pulldown Demand Time
Full Load Amps
Voltage Range
Starting Current
Open SCR
Shorted SCR
VARIABLE SPEED DRIVE SCREEN
SETPOINT
Local Motor Current Limit
Pulldown Demand Limit
Pulldown Demand Time
Filter Inhibit
VARIABLE SPEED DRIVE DETAILS SCREEN (VARIABLE SPEED DRIVE SUBSCREEN)
SETPOINT
Local Motor Current Limit
Pulldown Demand Limit
Pulldown Demand Time
ADAPTIVE CAPACITY CONTROL DETAILS SCREEN (VARIABLE SPEED DRIVE SUBSCREEN)
SETPOINT
Local Motor Current Limit
Pulldown Demand Limit
Pulldown Demand Time
Stability Limit
Surge Margin Adjust
ACC Auto Map Print
HARMONIC FILTER (VARIABLE SPEED DRIVE SUBSCREEN)
SETPOINT
Local Motor Current Limit
Pulldown Demand Limit
Pulldown Demand Time
JOHNSON CONTROLS
APPENDIX B - PROGRAMMABLE SETPOINT VALUES
ACCESS MINIMUM
LEVEL VALUE
Operator 30 %
Operator 30 %
Operator 0 Min
Service 35 Amps
Disabled, 200-208, 220-240, 380,
Service
400, 415, 440-480, 550 – 600
Service 310 Amps
Service Disabled
Service Disabled
ACCESS MINIMUM
LEVEL VALUE
Operator 30 %
Operator 30 %
Operator 0 Min
Service Disabled
ACCESS MINIMUM
LEVEL VALUE
Operator 30 %
Operator 30 %
Operator 0 Min
ACCESS MINIMUM
LEVEL VALUE
Service 30 %
Service 30 %
Service 0 Min
Service 1000
Service 0.0 Hz
Service Disabled
ACCESS MINIMUM
LEVEL VALUE
Operator 30 %
Operator 30 %
Operator 0 Min
MAXIMUM
DEFAULT
VALUE
100 % 100 %
100 % 100 %
255 Min 0 Min
1050 Amps 35 Amps
Disabled
3300 Amps 310 Amps
Enabled Disabled
Enabled Enabled
MAXIMUM
DEFAULT
VALUE
100 % 100 %
100 % 100 %
255 Min 0 Min
Enabled Disabled
MAXIMUM
DEFAULT
VALUE
100 % 100 %
100 % 100 %
255 Min 0 Min
MAXIMUM
DEFAULT
VALUE
100 % 100 %
100 % 100 %
255 Min 0 Min
7000 4500
25.0 Hz 0.0 Hz
Enabled Disabled
MAXIMUM
DEFAULT
VALUE
100 % 100 %
100 % 100 %
255 Min 0 Min
