5.3.1.1 Connection scheme for a test chamber

Example of an
individually
manufactured test
chamber
ELT3000-Battery Leak-Detector-Operating-instructions-mina95en1-10-(2007)
The power switch is used to switch the device on and off.
5. Electrical fuses behind cover
6. Power cable connection
DANGER
Risk of implosion
The evacuated test chamber must be able to withstand strong forces from the outside
due to the atmospheric pressure.
Even a very full test chamber must have small channels that allow gas from potential
leaks to be transported to the evacuation connection.
1 2
Fig. 1: Example of test chamber
1 Venting test chamber connection
2 Exhaust air test chamber
connection
3 Liquid separator
4 Red LED indicator
5 Green LED indicator
3
9 8
6 Rubber feet (4x)
7 Cover handle
8 Lid
9 Test chamber housing
Installation | 5
4
5
7 6
