5 | Installation
Gas detection unit
28 / 74
1 Display
2 GDU A, Ø 6 mm
3 Exhaust, Ø 8 mm
4 GDU B, Ø 6 mm
Back view
1 2
1 Headphone port
2 I/O port, inputs/outputs
3 RS232 interface
1. Headphone port:
Not used in this case.
2. I/O port, inputs/outputs:
Not used in this case.
3. RS232 interface:
Gas Detection Unit connection to Gas Control Unit.
4. Power switch:
ELT3000-Battery Leak-Detector-Operating-instructions-mina95en1-10-(2007)
1
3
4
5
6
2 3 4
4 5 6
Power switch
Fuses behind cover
Power supply
INFICON
