Technical Specifications; Mechanical Data - Inficon ELT3000 Translation Of The Original Operating Instructions

INFICON
Measurement result:
Warning

4.3 Technical specifications

4.3.1 Mechanical data

Gas Control Unit
Gas detection unit
ELT3000-Battery Leak-Detector-Operating-instructions-mina95en1-10-(2007)
If the leak rate is above the setpoint for warning but still below the setpoint for leaks,
the measurement result is shown on an orange background.
Leak Warning
Setpoint Leak
Mechanical data
Dimensions (W x H x D)
Weight
Mechanical data
Dimensions (W x H x D)
Weight
700 mm x 540 mm x 250 mm
32 kg
610 mm x 300 mm x 380 mm
33 kg
Description | 4
19 / 74
