Open-Q™ 2100 Development Kit based on the Snapdragon™ 2100 (APQ8009W) Processor User Guide Version 1.4

3.8.3 Hardware Specification

The Open-Q 2100 SOM platform encompasses the following hardware features:
Subsystem / Feature Set
Connectors
Chipset APQ8009W
PMIC (PM8916-1)
Memory 512MB LPDDR3,
4GB eMMC
Connectivity Wi-Fi 2.4 GHz via
WCN3620
BT 2.4 GHz via
WCN3620
GNSS via
WGR7640 – SSBI
Qualcomm®
Proprietary
Protocol
RF Interfaces 1xWLAN / BT
U.FL antenna
connector
1x GPS
Interfaces 1 x MIPI CSI
1 x USB HS
1 x MIPI DSI
Connector 2 x board to board
connector

3.8.4 SOM RF Specification for WIFI, BT, GNSS

The SOM includes the following radio interfaces:
o Wi-Fi + BT: Antenna 1
o GNSS: Antenna 2
Table 3.8-2 Open-Q 2100 SOM Hardware Features
Description
Qualcomm® Snapdragon™
2100 Processor
Qualcomm® PMIC,
Companion PMIC for
APQ8009W processor
Memory POP
Wi-Fi Qualcomm WCN3620
Wi-Fi + BT Combo Chip
WCN3620
Wi-Fi + BT Combo Chip
GNS Receiver Frontend
Connect to antenna on
carrier board via coax cable
Connect to external antenna
Connect to camera
Connectors
CSI0
Connect to 2 x dual stack
type A USB2.0 via USB line,
1 x micro USB B 2.0 via
switch (from USB line)
Connect to 51- pin display
connector. Interfaces with
Intrinsyc Display Adapter
Board
Connectors to interface with
carrier board
Copyright Intrinsyc Technologies Corporation
Specification
ARM Cortex-A7 CPU, quad
core, 32-bit up to 1.09GHz
NA
Up to 533MHz LPDDR3 POP
on CPU BGA chip. Supports
via 4x32bit channels
802.11b/g/n 2.4 GHz via
WCN3620.
Support BT 4.0
GPS, GLONASS, COMPASS
2.4 GHz WLAN antenna
GPS/GLONASS/COMPASS
passive or active antenna
MIPI Alliance Specification
v1.0
USB2.0
MIPI Alliance Specification
v1.01. MIPI D-PHY
Specification v0.65, v0.81,
v0.90, v1.01
Hirose DF40C series 100pin
connector
