2: System Control
16
Local Area Network (LAN)
SGIconsole
Local Area Network (LAN)
NUMAlink cable (USB signals used)
Xtown2 (RS-422 signals used)
IX-brick
Figure 2-1 SGI Altix 3700 Bx2 Server System Control Network (Example)
Remote
workstation
monitor
CR-brick
CR-brick
CR-brick
CR-brick
Type A USB
to Enet adapter
007-4377-002
