12: Maintenance and Upgrade Procedures
150
Figure 12-13 Unlocking the Anti-Tamper Lock
2. Release the carrier handle by pressing the latch in the handle towards the right.
3. Gently withdraw the drive carrier module approximately 1 inch (25 mm), and then
wait 30 seconds for the drive to spin down.
4. After 30 seconds, withdraw the module from the drive bay.
Torx screwdriver
007-4377-002
