13: Troubleshooting and Diagnostics
L1 Controller Error Messages
164
Table 13-2 lists error messages that the L1 controller generates and displays on the L1
display. This display is located on the front of the CR-bricks, R-bricks, IX-brick, and
PX-bricks.
Note: In Table 13-2, a voltage warning occurs when a supplied level of voltage is below
or above the nominal (normal) voltage by 10 percent. A voltage fault occurs when a
supplied level is below or above the nominal voltage by 20 percent.
L1 Controller Messages
Table 13-2
L1 System Controller Message
Internal voltage messages:
ATTN: <power VRM description> high fault limit
reached @ x.xxV
ATTN: <power VRM description> low fault limit
reached @ x.xxV
ATTN: <power VRM description> high warning
limit reached @ x.xxV
ATTN: <power VRM description> low warning
limit reached @ x.xxV
ATTN: <power VRM description> level stabilized
@ x.xxV
Fan messages:
ATTN: FAN <fan description> fault limit
reached @ xx RPM
ATTN: FAN <fan description> warning limit
reached @ xx RPM
ATTN: FAN <fan description> stabilized @ xx
RPM
Message Meaning and Action Needed
30-second power-off sequence for the brick.
30-second power-off sequence for the brick.
A higher than nominal voltage condition is
detected.
A lower than nominal voltage condition is
detected.
A monitored voltage level has returned to
within acceptable limits.
A fan has reached its maximum RPM level. The
ambient temperature may be too high. Check to
see if a fan has failed.
A fan has increased its RPM level. Check the
ambient temperature. Check to see if the fan
stabilizes.
An increased fan RPM level has returned to
normal.
