External Components

Front Panel Components

007-4377-002
This section describes the external components located on the front and rear panels of the
power bay.
The front of the power bay seats the distributed power supplies (see Figure 9-2). When
the power bay contains three power supplies, the supplies reside in locations 4, 5, and 6.
Power supply 1
Power supply 2
Power supply 3
Power supply 4
Power supply 5
Power supply 6
Figure 9-2 Front View of Power Bay
