1: Operation Procedures
6
4. Make sure that the PDU and PDS circuit breaker switches shown in Figure 1-4 are
turned on to give power to the server system when the system is powered on.
PDS
Figure 1-4 PDU and PDS Circuit Breaker Switches
Note: Verify that the LEDs turn on and light green and that your controllers display that
the system is powered on for each segment of the procedure, which indicates that the
power-on procedure is proceeding properly. If you have a problem while powering on
and an error message appears on the L1 controller, or the system console, see your online
log files and the information in "L1 Controller Error Messages" on page 164 to learn what
the error message indicates and how to resolve the problem.
Circuit breaker
switch
PDU
007-4377-002
