A: Technical Specifications and Pinouts
Physical Specifications
170
Table A-2 shows the physical specifications of the Altix 3700 Bx2 system.
Table A-2 Altix 3700 Bx2 Physical Specifications
Feature
Dimensions for a single tall rack,
including doors and side panels
Shipping dimensions
Weight (maximum)
Compute rack
I/O rack
Disk rack
Shipping weight (maximum)
Compute rack
I/O rack
Disk rack
Access requirements
Front
Rear
Side
Specification
Height: 74.25 in. (1886 mm)
Width: 30.88 in. (784 mm)
Depth: 53.27 in. (1353 mm)
Height: 80 in. (2032 mm)
Width: 41.5 in. (1054 mm)
Depth: 62.75 in. (1594 mm)
1400 lb (635 kg)
1225 lb (556 kg)
1400 lb (635 kg)
1785 lb (810 kg)
1588 lb (720 kg)
1785 lb (810 kg)
48 in. (1219 mm)
48 in. (1219 mm)
None
