8: R-brick
98
Failure LED
Service-required LED
Front View of the R-Brick
Figure 8-1
The R-brick has the following features:
• Eight NUMAlink channels
• One USB port for system controller support
• One L1 controller and LCD display
• Two hot-pluggable cooling fans
Figure 8-2 shows a block diagram of the R-brick.
L1 controller display
Power button
with LED
007-4377-002
