Technical specifications

Technical specifications
General specifications General specifications
Power Power
Motor torque Motor torque
Max power Max power
Operating class Operating class
Battery Battery
Overall dimensions Overall dimensions
Weight Weight
Operating temperature Operating temperature
IP Grade IP Grade
Opening / closing time Opening / closing time
Pause time Pause time
Power for auxiliary devices Power for auxiliary devices
Power for electrolock Power for electrolock
Electrolock output relay Electrolock output relay
Open door output relay Open door output relay
Electrolock hold time Electrolock hold time
Power failure autonomy Power failure autonomy
RX memory RX memory
Integrated receiver main specififications Integrated receiver main specififications
Fire voltage input Fire voltage input
Max Door opening angle Max Door opening angle
Use conditions Use conditions
Zone A : Very intense use : 600 cycles / day Zone A : Very intense use : 600 cycles / day
Zone B : : Intense use Zone B Intense use : 200-300
Zone C : Use at reduced speed Zone C : Use at reduced speed
Zone D : Not allowed Zone D : Not allowed
Inward or Outward Door Operator
: 200-300 cycles / day cycles / day
DIGIWAY Plus
230 Vac - 50 Hz 15 Nm 230 Vac - 50 Hz 15 Nm
15 Nm 15 Nm
50 W 50 W
5 (heavy duty) 5 (heavy duty)
12 Vdc 1,3 Ah 12 Vdc 1,3 Ah
511 x 90 x 110 mm 511 x 90 x 110 mm
5kg 5kg
-10°C ÷ +55°C -10°C ÷ +55°C
IP40 IP40
3 ÷ 15 sec. 3 ÷ 15 sec.
3 ÷ 90 sec. 3 ÷ 90 sec.
13.5 Vdc / 500 mA [max] 13.5 Vdc / 500 mA [max]
12 Vdc / 1A [max] 12 Vdc / 1A [max]
(C-NO-NC) 10A / 12V (C-NO-NC) 10A / 12V
(C-NO) - 24 VA (C-NO) - 24 VA
Adjustable [0.l1 ÷ 5 min] Adjustable [0.l1 ÷ 5 min]
270 cycles / 16 hours 270 cycles / 16 hours
Keeloq® Hopping Code 50 transmitters Keeloq® Hopping Code 50 transmitters
433.92 MHz ASK / -107 dBm 433.92 MHz ASK / -107 dBm
24 ÷ 48 Vac/dc 24 ÷ 48 Vac/dc
Leaf width Leaf width
