7] BLUETOOTH CONNECTION & MANAGEMENT 7] BLUETOOTH CONNECTION & MANAGEMENT
The appliance can be provided from the factory with a plug-in Bluetooth module that The appliance can be provided from the factory with a plug-in Bluetooth module that
allows you to manage the settings using a smartphone. allows you to manage the settings using a smartphone.
The models with the Bluetooth module The models with the Bluetooth
name. The Bluetooth name. The Bluetooth module
CD on the part name). CD on the part name).
The Bluetooth module allows the unit to communicate with a Smartphone with iOS The Bluetooth module allows the unit to communicate with a Smartphone with iOS
(Apple) or Android. The Bluetooth communication will make the display of the Digiway (Apple) or Android. The Bluetooth communication will make the display of the Digiway
visible on the screen of your smartphone, even when the aluminium cover is installed. visible on the screen of your smartphone, even when the aluminium cover is installed.
This makes any configuration and service intervention easier. This makes any configuration and service intervention easier.
Type P/N
DWMBT F0543000179
Installing the Bluetooth module on a DIGIWAY Plus Installing the Bluetooth module on a DIGIWAY Plus
1) Remove the cover
2) Power off the unit!
3) Disconnect the batter cable!
4) Plug-in the polarized module connector
onto the white 6-poles connector of the
DIGIWAY board
5) Fold the flat cable of the module
inward
6) Reconnect the battery cable
7) Power the unit
8) Replace the cover
Technical Specifications
Communication w/mobile phone: ................Bluetooth
Standard: .................................................BLE 4.2
Power supply:
OS Compatibility: ......................................Android, iOs
Release Android: .......................................5.1 and next
Release iOS: .............................................10 and next
Compatibility SW DIGIWAY-SR: ...................2.8a and next
40
DIGIWAY Plus
Inward or Outward Door Operator
module are identified with the suffix BT on the part-
module can be plugged in a second time on regular units (suffix can be plugged in a second time on regular units (suffix
BLUETOOTH PLUG-IN MODULE FOR DIGIWAY PLUS
......................................3 Vdc
are identified with the suffix BT on the part-
Description
Flat cable
Monitor 2 red/green leds
6-poles connector
EN
