CDVI DIGIWAY Plus Manual page 41

EN
Monitor RED/GREEN LED messages
9 dots give the status of the corresponding leds of the mother board (*).
Red LED Green LED
OFF Blinking
Blinking Blinking
Blinking Fixed
(*) The correct functionality of the first dot on the left of the App that monitors the "FIRE" led is guaranted if the firmware revision installed on Digiway is
Digiway Plus : > 2.8a. For all previous firmware revisions, the management of the "Fire" LED is not implemented. The dot of the App does not indicate
the correct status of the fire function. All other features are guaranteed.
Installing the App on the smartphone Installing the App on the smartphone
For communication with the module it is necessary to install the correct App on your For communication with the module it is necessary to install the correct App
smartphone, from either the App Store (Apple) or Google Play (Android). smartphone , from either the App Store (Apple) or Google Play (Android). The App
allows to program and control the operator. allows to program and control the operator.
Once the download is completed, start the App. Once the download is completed, start the App.
1
Inward or Outward Door Operator
Status
Module operating in stand-by
Bluetooth connection in progress. App not logged
Connected and logged-in
Search CDVI or Digiway BLE on the App Store Search CDVI or Digiway BLE on the App Store
and proceed with the download. and proceed with the download.
Search CDVI or Digiway BLE on Google Play Search CDVI or Digiway BLE on Google Play
and proceed with the download. and proceed with the download.
2
You will be asked to You will be asked to
specify the language specify the language
of the App: select the of the App: select the
language and press OK. language and press OK.
DIGIWAY Plus
3
on your
The App
The App will start The App will start
searching the Bluetooth searching the Bluetooth
modules present in the modules present in the
area, displaying all the area, displaying all the
modules found and their modules found
field strength.
