Electronic card specifications Electronic card specifications
Operating modes: Automatic ( I ) - Door free ( 0 ) - Door always open (II) Operating modes:
Inputs: Inputs: Re-open photocells ( NC) Re-open photocells ( NC)
Stop photocells ( NC ) Stop photocells ( NC )
Door Alway open Door Alway open ( NO )
Door free ( NO ) Door free ( NO )
External Radar ( NO ) External Radar ( NO )
Internal Radar ( NO ) Internal Radar ( NO )
Day / Night selection ( NO ) Day / Night selection ( NO )
Open / Close command ( NO ) Open / Close command ( NO )
Fire alarm voltage ( +V, -V ) [optoisolated] Fire alarm voltage ( +V, -V ) [optoisolated]
Outputs: Outputs: Door open contact ( C-NO ) Door open contact ( C-NO )
External devices power 13,5 Vdc / 500 mA External devices power 13,5 Vdc / 500 mA
Electrolock output contacts ( C-NO-NC ) Electrolock output contacts ( C-NO-NC )
Electrolock power 12 Vdc / 1 A Electrolock power 12 Vdc / 1 A
Test for safety devices ( FTC- FTC-S ) Test for safety devices ( FTC- FTC-S )
Main features Main features
• • Operating modes: Fully automatic, Door open, Door free/ operation off; Operating modes: Fully automatic, Door open, Door free/ operation off;
• • Operating with single door, double door, with or without leaf overlapping; Operating with single door, double door, with or without leaf overlapping;
• • Guided procedure for door travel limits characterisation; Guided procedure for door travel limits characterisation;
• • Adjustable motor torque during open and close phases; Adjustable motor torque during open and close phases;
• • Remote controls memorization and management; Remote controls memorization and management;
• • Auto slow down during approach to door limits; Auto slow down during approach to door limits;
• • Push & Go / Pull & Go function; Push & Go / Pull & Go function;
• • Pause Time, Max Speed, Torque, Velocity adjustable; Pause Time, Max Speed, Torque, Velocity adjustable;
• • Opening Jolt fully adjustable; Opening Jolt fully adjustable;
• • Status bicolor LED; Status bicolor LED;
• • Electrolock hold time and torque adjustable; Electrolock hold time and torque adjustable;
• • Opening Jolt parameters adjustable; Opening Jolt parameters adjustable;
• • Spring mode (Door always free, spring simulation with auto closing); Spring mode (Door always free, spring simulation with auto closing);
• • Stop and reopen photocell inputs; Stop and reopen photocell inputs;
• • "Fire mode"; "Fire mode";
• • Night / day mode; Night / day mode;
• • Door open output relay (gives open volt free contact whilst door is open). Door open output relay (gives open volt free contact whilst door is open).
10
DIGIWAY Plus
Inward or Outward Door Operator
Automatic ( I ) - Door free ( 0 ) - Door always open (II)
( NO )
EN
