Connection detail
Connection detail
19-way terminal block
1
Output C Door Open Relay
2
Output NO Door Open Relay
3
Input V- Fire alarm voltage
4
Input V+ Fire alarm voltage
5
Safety Input NC Stop Photocells [FTC-S]
6
Safety Input C Photocells
7
Safety Input NC Re-open Photocells [FTC]
8
Input NO switch pos. I
9
Input C switch pos. 0
10
Input NO switch pos. II
11
Input NA Radar external
12
Input C Radar
13
Input NO Radar internal
14
Input NO Day/Night switch
15
Input common
16
Input NO push-button open/close/stop
T1
Output (+12) Test FTC-S
C
Common test photocells ( GND)
T2
Output (+12) Test FTC
Door Status
Closed
Relay
OFF
Monitored photocells wiring
Monitored photocells wiring
The Standard EN16005 indicates that the parts of the system which have a direct effect
The Standard EN16005 indicates that the parts of the system which have a direct effect
on safety must comply with EN12978 and be designed to comply with EN ISO 13849-1
on safety must comply with EN12978 and be designed to comply with EN ISO 13849-1
Performance Level "C". Safety related parts of the control system used for escape route
Performance Level "C". Safety related parts of the control system used for escape route
functionality shall comply with EN ISO 13849-1 Performance Level "D".
functionality shall comply with EN ISO 13849-1 Performance Level "D".
If devices type ESPE (photocells) are used, they must be monitored by the drive system.
If devices type ESPE (photocells) are used, they must be monitored by the drive system.
DIGIWAY Plus is equipped with output test signals (Test1, C, Test2) that check the
DIGIWAY Plus is equipped with output test signals (Test1, C, Test2) that check the
photocells' status before any motion. The system switches the photocell off and back
photocells' status before any motion. The system switches the photocell off and back
on within a few mS to detect a change of the safety signal on terminals 5-6 and 6-7.
on within a few mS to detect a change of the safety signal on terminals 5-6 and 6-7.
If the signal change is regular, door motion is enabled, otherwise the motion is stopped
If the signal change is regular, door motion is enabled, otherwise the motion is stopped
or enabled in low energy mode (see the Advance Options menu).
or enabled in low energy mode (see the Advance Options menu).
16
DIGIWAY Plus
Inward or Outward Door Operator
Door open relay
Opening/Open/Closing
ON
7-way terminal block
17
Output NO relay electrolock
18
Output C relay electrolock
19
Output NC relay electrolock
20
Output 0V external devices power
21
Output 13,5 Vdc external devices power
22
Output 0V electrolock power
23
Output 12 Vdc electrolock power
2-way terminal block
24
Input Line 230 Vac
25
Input Neutral 230 Vac
2-way terminal block
26
Output 230 Vac to internal toroidal transformer
27
Output 230 Vac to internal toroidal transformer
2-way terminal block
28
Input Motor BLACK cable
29
Input Motor RED cable
2-way terminal block
30
Input from internal toroidal transformer
31
Input from internal toroidal transformer
EN
