Mounting diagram Mounting diagram
Screws for plugs SX8 Screws for plugs SX8
Plugs SX8 Plugs SX8
Sliding arm Sliding arm
Screw M6x14 Screw M6x14
provided provided
Articulated arm Articulated arm
Universal Arm Universal Arm
The universal arm can be assembled for use with an inward opening door (pull - sliiding) The universal arm can be assembled for use with an inward opening door (pull - sliiding)
or an outward opening door (push - articulated). The DWP comes with an assembled or an outward opening door (push - articulated). The DWP comes with an assembled
sliding arm as standard. To change the arm assembly to articulated; remove the sliding sliding arm as standard. To change the arm assembly to articulated; remove the sliding
block by unscrewing from the arm (requires a 13mm AF spanner), once removed block by unscrewing from the arm (requires a 13mm AF spanner), once removed
assemble the adjustable articulated fore arm to the fixed by screwing fixed bolt into assemble the adjustable articulated fore arm to the fixed by screwing fixed bolt into
the threaded hole left by removing the sliding block. the threaded hole left by removing the sliding block.
Screw M6x14 Screw M6x14
provided provided
8
DIGIWAY Plus
Inward or Outward Door Operator
Cover lift point Cover lift point
Washer Washer
Screw M6x14 Screw M6x14
provided provided
M6x14 M6x14
Turn clockwise Turn clockwise
M6x14 M6x14
M6x14 M6x14
Turn anti-clockwise Turn anti-clockwise
