1] IDENTIFYING THE PRODUCT AND ITS PARTS 1] IDENTIFYING THE PRODUCT AND ITS PARTS
DIGIWAY type DWPx102xx is an indoor operator for swing doors, with integrated electronic DIGIWAY type DWPx102xx is an indoor operator for swing doors, with integrated electronic
controller and radio receiver. The opening and closing motion is electromechanical with controller and radio receiver. The opening and closing motion is electromechanical with
backup battery which assures the operation in cases of power failure. backup battery which assures the operation in cases of power failure.
The following versions are available: The following versions are available:
P/N
F0543000093 F0543000093 DWPS102SCD
F0543000094 F0543000094 DWPS102ACD
F0543000095 DWPS102UCD
The operator is suitable for swing doors with max width of 1.2 m or max weight of The operator is suitable for swing doors with max width of 1.2 m or max weight of
120kg (refer to diagram on page 7). At max speed the door can open and close within 120kg (refer to diagram on page 7). At max speed the door can open and close within
3 sec. (90°), depending on door weight and dimensions. 3 sec. (90°), depending on door weight and dimensions.
See the technical specififications in the following pages of this manual. See the technical specififications in the following pages of this manual.
Warning : the operator is suitable only for top-jamb fixing. Door leaf Warning : the operator is suitable only for top-jamb fixing. Door leaf
fixing is not allowed. fixing is not allowed.
1
3
10
Legend Legend
1 - Anodized aluminium cover 1 - Anodized aluminium cover
2 - Motor shaft 2 - Motor shaft
3 - Status led LP 3 - Status led LP
4 - 4 - Receiver Card Receiver Card
5 - Display LCD 5 - Display LCD
6 - 5-buttons keyboard 6 - 5-buttons keyboard
7 - 7 - Gear box Gear box
8 - 8 - Motoriductor Motoriductor
6
DIGIWAY Plus
Inward or Outward Door Operator
Reference
Single door operator for inswing doors with sliding arm Single door operator for inswing doors with sliding arm
Single door operator for outswing doors with articulated arm Single door operator for outswing doors with articulated arm
Single door operator for inswing or outswing doors with universal arm Single door operator for inswing or outswing doors with universal arm
4 5 6
Description
2
7 8
12
11 13
9 - 9 - Encoder Encoder
10 - Slot for cover opening 10 - Slot for cover opening
11 - 11 - Toroidal transformer Toroidal transformer
12 - 12 - Backup battery Backup battery
13 - Battery cable with protection fuse 13 - Battery cable with protection fuse
14 - 14 - Jumper for external selector exclusion Jumper for external selector exclusion
15 - Operating mode selector 15 - Operating mode selector
9
14 15
