2] INSTALLATION 2] INSTALLATION
Important: Check the integrity of the door that is to be automated, verifiying Important: Check the integrity of the door that is to be automated, verifiying
the operation in both directions is smooth without any friction from the closed the operation in both directions is smooth without any friction from the closed
to open position and the open to closed position. If this is not the case, make to open position and the open to closed position. If this is not the case, make
any repairs or improvements necessary to achieve a smooth operation of the any repairs or improvements necessary to achieve a smooth operation of the
door. Remove any manually operated locking mechanism unless it is to be door. Remove any manually operated locking mechanism unless it is to be
used with a strike. A door stop is not required to complete the opening cycle. used with a strike. A door stop is not required to complete the opening cycle.
Warning: Any existing closing device should be removed to allow the door to move Warning: Any existing closing device should be removed to allow the door to move
freely. Hydraulic devices MUST be replaced with dummy units as adjusting the device freely. Hydraulic devices MUST be replaced with dummy units as adjusting the device
will not allow the Digiway to operate correctly. will not allow the Digiway to operate correctly.

Sliding arm version

Sliding arm version
Inward or Outward Door Operator
Value
Parameter
(mm)
A A 240 240
B B 35 35
C C 100 100
D D 500 500
E E 18,5 18,5
F F 70,5 70,5
DIGIWAY Plus
Description
Door hinge – motor axis distance Door hinge – motor axis distance
Backplate – guide distance Backplate – guide distance
Motor axis - guide edge Motor axis - guide edge
Guide width Guide width
Distance hinges - backplate hole Distance hinges - backplate hole
Motor axis - vertical plane distance Motor axis - vertical plane distance
