CDVI DIGIWAY Plus Manual page 28

Advanced Setting
17) 17)
Approach speed
It is possible to change the approach speed as the door approaches the final close point. This is It is possible to change the approach speed as the door approaches the final close point. This is
useful if the door senses an obstacle or finishes short of a strike. The door will accelerate a small useful if the door senses an obstacle or finishes short of a strike. The door will accelerate a small
amount when increased. amount when increased.
Default value = 5 Default value = 5
Advanced Setting
18) 18)
Obst. detection %
It is possible to change the percentage at which the does not detect an obstacle during the full door It is possible to change the percentage at which the does not detect an obstacle during the full door
cycle allowing the door to close. cycle allowing the door to close.
100% = fully open, 0% = fully close 100% = fully open, 0% = fully close
Advanced Setting
19) 19)
Min Open Speed
It is possible to change the approach speed during the OPENING. It is possible to change the approach speed during the OPENING.
This can be useful if the door finds some friction in the last approaching motion where it is searching This can be useful if the door finds some friction in the last approaching motion where it is searching
for the open position. for the open position.
Default value = 5 Default value = 5
Advanced Setting
20) 20)
% Min Open Speed
It is possible to change the percentage of the complete open It is possible to change the percentage of the complete
the value set with the parameter "Min Open Speed". the value set with the parameter "Min Open Speed".
Default value = 2% Default value = 2%
21) 21) Advanced Setting
O.D. Cycle
It is possible to set the type of cycle after an obstacle detection: It is possible to set the type of cycle after an obstacle detection:
FAST: FAST: the door keeps normal speed after the detection of an obstacle the door keeps normal speed after the detection of an obstacle
SLOW: the speed of the door after an obstacle is reduced. SLOW : the speed of the door after an obstacle is reduced.
Advanced Setting
22) 22)
Test FTC
It is possible to disable the test on the re-open photocell It is possible to disable the test on the re-open photocell FTC:
ATTENTION!!: If the test is DISABLED the operator must work in Low Energy Mode ATTENTION!!: If the test is DISABLED the operator must work in Low Energy Mode
otherwise it doesn't operate in compliance with the Standard EN16005. otherwise it doesn't operate in compliance with the Standard EN16005.
Advanced Setting
23) 23)
Test FTC-S
It is possible to disable the test on the stop photocell It is possible to disable the test on the stop photocell FTC-S:
ATTENTION!!: If the test is DISABLED the operator must work in Low Energy Mode ATTENTION!!: If the test is DISABLED the operator must work in Low Energy Mode
otherwise it doesn't operate in compliance with the Standard EN16005. otherwise it doesn't operate in compliance with the Standard EN16005.
Advanced Setting
24) 24)
Test FTC Fail
In case of malfunction of the safety photocells FTC it's possible to set the operating mode: In case of malfunction of the safety photocells FTC it's possible to set the operating mode:
STOP / LOW ENERGY motion STOP / LOW ENERGY motion
28
DIGIWAY Plus
Inward or Outward Door Operator
Approach speed
5
|||||||||||||||||......................
Obst. detection %
2%
|||||||||||||||||......................
Min Open Speed
5
|||||||||||||||||......................
% Min Open Speed
.2%
|||||||||||||||||..................
O.D. Cycle:
Fast
ENABLED /
DISABLED
ENABLED /
DISABLED
STOP /
LOW ENERGY
open trip after which the speed remains at trip after which the speed remains at
FTC:
FTC-S:
EN
