Step II allows the set up of all the basic parameters of the operator depending on Step II allows the set up of all the basic parameters of the operator depending on
the door type that is being automated. The submenu CONFIGURATION consists of 18 the door type that is being automated. The submenu CONFIGURATION consists of 18
parameters. Each parameter can have 2 or more values. For each parameter there is parameters. Each parameter can have 2 or more values. For each parameter there is
a preset factory value. If the function FACTORY DEFAULT of the main menu is used, all a preset factory value. If the function FACTORY DEFAULT of the main menu is used, all
the parameters are reset to those values. the parameters are reset to those values.
See the description of each parameter in the following table: See the description of each parameter in the following table:
Parameter
Num. Doors
Sets the number of Doors
Electrolock Enables electrolock and specify the type
Enables the opening Jolt: SORT CLOSING PULSE BEFORE
Opening Jolt OPENING, useful when using an electric strike to stop
binding.
Push & Open Opens automatically the door with a short push.
Push & Close Closes the door with a short push even in pause status.
Keeps the door closed in presence of wind which pushes the
Wind Stop door. See ADVANCED SETTINGS to set the level of the
closing force used.
Autoreclosing Enables the automatic reclosing of the door
INTERNAL radar operating mode. If it's selected the
option CLOSING the radar is excluded during the closing.
Radar 'I' Mode
This prevents the door reopening if the arm or door is
detected. (*)
EXTERNAL radar operating mode. If it's selected the
option CLOSING the radar is excluded during the closing.
Radar 'E' Mode
This prevents the door reopening if the arm or door is de-
tected. (*)
Set the Night / Day mode. In Night mode the External radar
Day / Night
is disabled.
Disabled access mode (see paragraph Disabled Access set-
Disabled Mode
tings)
Optional functions for the open command; Open, Close or
Open Command Stop. Once selected the function will operate from the open
button (terminals 15 - 16) and the radio transmitter.
If the door is closed it will remain free and can be pushed/
pulled manually; if opened fully the will close after the preset
Spring Mode pause time.
Note: If the door is partially opened up to 75% the pause
time will be 1 sec and will close after .
Overlap of the leaves (in case of double doors). The MASTER
2 Doors Overlap leaf starts opening first, the SLAVE starts closing first. If
disabled the doors open simultaneously.
Door Type Leaf MASTER or leaf SLAVE ( in case of double doors )
Articulated or sliding arm. This parameter set the VELOCITY
of the door according to the arm type selected.
Arm Type
(see Adjustments)
50% ARTICULATED ARM, 70% SLIDING ARM
Fire signal management. When this option is enabled the
door opertates normally if the fire voltage is present V+/V-.
Fire Signal
If the fire power is removed(fire alarm triggered) the door
reacts to the option set in the advanced settings.
(*) Please Note: the door must fully close before it can be opened again.
Inward or Outward Door Operator
STEP II: CONFIGURATION
Description
DIGIWAY Plus
Option
ONE DOOR / TWO DOORS
NO LOCK / STRIKE / MAG-
NET
ENABLE / DISABLE
ENABLE / DISABLE
ENABLE / DISABLE
ENABLE / DISABLE
ENABLE / DISABLE
NEVER / CLOSING / ALWAYS
NEVER / CLOSING / ALWAYS
DAY & NIGHT / NIGHT
ENABLE / DISABLE
OPEN - OPEN/CLOSE -
OPEN-CLOSE/STOP
ENABLE / DISABLE
ENABLE / DISABLE
MASTER / SLAVE
SLIDING / ARTICULATED
ENABLE / DISABLE
Default
ONE DOOR
NO LOCK
DISABLE
ENABLE
ENABLE
DISABLE
ENABLE
NEVER
NEVER
NIGHT
DISABLE
OPEN/
CLOSE
DISABLE
DISABLE
MASTER
SLIDING
DISABLE
