Pin# CAM0 (J5)
37 CAM_IRQ
(APQ_GPIO24)
38 CAM0_MCLK3
(APQ_GPIO13)
39 MB_ELDO_CAM0_
DVDD
40, MB_VREG_5P0
41 (DNP)
Install R10 to
access rail
Note: A connection from the camera connectors on the carrier board to the Lantronix camera adapter board is
established by a 41-pin cable assembly from JAE Electronics (part number JF08R0R041020MA)
The following table shows the combinations of camera usage for different use cases
CSI PHY
CSI0
CSI 1
CSI 2
Open-Q™ 820 / 820Pro µSOM Dev Kit User Guide
CAM1 (J4)
CAM_IRQ (DNP)
(APQ_GPIO24)
Install R40 to access
signal
CAM1_MCLK3
(APQ_GPIO13)
MB_ELDO_CAM1_D
VDD
MB_VREG_5P0
Install R28 to access
rail
Table 3.8.20-2. MIPI CSI Camera Use Cases
Use case
Up to 4 lane One Camera of 4 lane or
One camera of 3 lane
One Camera of 2 lane
One Camera of 1 lane
Up to 4 lane One Camera of 4 lane or
One camera of 3 lane
One Camera of 2 lane
One Camera of 1 lane
Up to 4 lane One Camera of 4 lane or
Open-Q 820 µSOM Development Kit
CAM2 (J3)
CAM_IRQ (DNP)
(APQ_GPIO24)
Install R46 to access
signal
CAM2_MCLK3
(APQ_GPIO13)
MB_ELDO_CAM2_D
VDD
MB_VREG_5P0
Install R35 to access
rail
Comment
Description
Input. Connected to
APQ8096 GPIO24.
CAM_IRQ signal
Output. Connected to
APQ8096 GPIO13. Default
N/C. Use is for secondary
camera master clock.
Maximum 24MHz
Power output. Connected
to U5, U6, and U71 AMS
LDO regulator. Default is
+1.2V. Maximum current
500mA
Power output. 5V Power
supply. Maximum 700mA
