Open-Q 820 µSOM Development Kit
Note that there is an unpopulated Gen-10 connector header (J55) footprint at the bottom of the carrier board.
Install the Samtec (part number: QSH-030-01-L-D-A) connector here if needed.
Figure 11 J55 Gen-10 Sensor Connector (Samtec QSH-030 series)
Open-Q™ 820 / 820Pro µSOM Dev Kit User Guide
33
