Display Signal

PM8996 LDO22 (3.3-2.8V)

PM8996 LDO14 (1.8V- 2.15V)

PM8996 LDO15(1.8V – 2.15V)

PM8996 S4A (1.8V)

Carrier 3.3V

Carrier 5 V

Carrier 12 V

The Lantronix Display Adapter is an additional PCB that mates with the display connector J2 on the carrier

board. This board allows users to interface with the development kit via the LCD that comes preinstalled on

the display board. The following figure illustrates the interfacing connectors on the display board.

Note: The display board comes as an additional add-on to the Open-Q 820 / 820Pro µSOM development kit.

To purchase this, please visit

Note: Please refer to "Open-Q 820 Development Kit Display Board Technical Note" for more information on

designing a custom display board.

Open-Q™ 820 / 820Pro µSOM Dev Kit User Guide

http://shop.intrinsyc.com

Open-Q 820 µSOM Development Kit

Power Domain

up to 150 mA

up to 300 mA

up to 0.5A

up to 1.5A

up to 0.5A

or contact Lantronix at

sales@lantronix.com

for details.
