Domain
VIP Extension
connector
Ethernet AVB connector
PCI Express Slot
Mini PCI Express
Connector
WWAN SIM Card (on
bottom)
CSI Camera connectors
Open-Q™ 820 / 820Pro µSOM Dev Kit User Guide
Description
Connector for interfacing
with Qualcomm® legacy
automotive VIP boards
Connector for interfacing
with Ethernet AVB
standard
PCI Express for external
peripheral connectivity
Mini PCI Express for
external peripheral
connectivity
WWAN SIM card
connector (optional)
3 x CSI port connector
with CLK, GPIOS, CCI
Open-Q 820 µSOM Development Kit
Specification
60 pin connector
60 pin connector
PCIe1 v2.1
Supports half card only
Supports 10W card via
power supply
Supports 25W card via ATX
power supply
PCIe1 v2.1
Can support half or full size
card
4bit Mini SIM card support
Supports 3 x Camera
interfaces via three
separate connectors
3 x MIPI-CSI each 4
•
lane
External flash driver
•
control
Usage
Can be used for other
purposes.
To connect to
Qualcomm® legacy
automotive VIP boards
(for Lantronix internal
use only – not
supported) Can be
used for other
purposes.
To connect to
automotive peripherals
via Ethernet AVB
standard (for Lantronix
internal use only – not
supported) Can be
used for other
purposes.
To connect an Ethernet
PCIe card board to
support Ethernet.
For external mini PCIe
card
For WWAN mini PCI
express cards
