3.5 Hardware Identification Label
Labels are present on the CPU board and the mini-ITX form-factor carrier board. The following information is
conveyed on these two boards:
CPU board (µSOM).:
• Serial Number
• WIFI MAC address
Refer to http://tech.intrinsyc.com/projects/serialnumber/wiki
number, as this will be needed to register the development kit. To register a development kit, please visit
https://tech.intrinsyc.com/account/register.
Mini-ITX form-factor carrier board:
Serial Number
•
Note: Please retain the µSOM and carrier board serial number for warranty purposes.
3.6 System Block Diagram
The Open-Q 820 / 820Pro µSOM development platform consists of three major components
o Open-Q 820 / 820Pro µSOM
o Carrier board for I/O and connecting with external peripherals
o Display Adapter Board (additional accessory)
The following diagram explains the interconnectivity and peripherals on the development kit.
