Overview
Key
MULTIPROP System
Instructions for Assembly and Use – Standard Configuration
Pictogram | Definition
Safety instructions
Note
Visual check
Tip
Lifting point
Safety helmet
Safety gloves
Safety shoes
Eye protection
PPE
Misapplication
Dimension specifications
Dimensions are usually given in mm and
m. Other measurement units, e.g. cm,
are shown in the drawings.
Load details are usually given in kg.
Other measurement units, e.g. t, are
shown in the illustrations.
Conventions
– Instructions are numbered
(1. ....., 2. ....., 3. .....)
– Multiple position numbers, i.e. alter-
native components, are represented
with a slash: 1 / 2.
Arrows
Actions
Forces
Presentational reference
The illustration on the front cover of
these instructions is understood to be
a system representation only.
The assembly steps presented in these
Instructions for Assembly and Use are
shown in the form of examples with
only one component size. They are
valid accordingly for all component sizes
contained in the standard configuration.
For a better understanding, detailed
illustrations are partly incomplete.
The safety installations which have
possibly not been featured in these
detailed drawings must nevertheless
be available.
