Peri MULTIPROP Instructions For Assembly And Use page 45

MULTIPROP Single Props and System
Item no. Weight kg
022027 3,600 Wing Nut Spanner HD
For easy release of the Head Spindle HDK 45, the
Head Spindle TR 110-80/55 and the MULTIPROP
slab prop.
027310 8,900 Base MP 50
For use with slab props with an end plate thick-
ness of 6 – 10 mm. With clamped quick-release
fastener.
027297 8,730 Tilting Forkhead MKK
For tilt-resistant support of one or two GT 24
or VT 20 Girders. Can be pivoted by 3° in all
directions. With clamped quick-release fastener.
027296 6,220 Tilting Base MKF
For use on inclined assembly areas.
Can be pivoted by 3° in all directions.
With clamped quick-release fastener.
983
Note
Permissible load: see PERI Design Tables.
150
Ø42
Ø 89
Technical Data
Separate design information on request.
240 155
170 85
Technical Data
Maximum permissible load 60 kN.
Ø 38
140
Ø38
Ø12,5
Ø6,5
150
80
Ø12,5
Ø12,5
43
