Peri MULTIPROP Instructions For Assembly And Use page 4

Overview
Accessories
3 Base MP 50
3.1 Head plate
3.2 Clamping claw
3.3 Centering pin
5 Tilting Forkhead MKK
5.1 Base plate
5.2 Clamping claw
5.3 Centering pin
5.4 Rotary wing
7 Connector MPV-2
7 .1 Clamping lever
7 .2 Clamping jaws
7 .3 Centering pin
9 Compression Brace Head MP/SRU
9.1 Fitting Pin 21 with Cotter Pin
2
3.1
3.2
3.3
5.4
5.1
5.2
5.3
7.2
7.1
7.3
9.1
4 Tilting Base MKF
4.1 Head plate
4.2 Clamping claw
4.3 Centering pin
4.4 Rotary wing
4.1
6 MULTIPROP Strap U100 – U140
6.1 Suspension fastening
6.2 Plate
6.3 Hex. bolt M16
6.4 Hex. nut M16, SW 24
8 MULTIPROP Bolt with Nut
8.1 Bolt M12
8.2 Nut M12
8.1
8.2
Instructions for Assembly and Use – Standard Configuration
4.2
4.3
4.4
6.3
6.4
6.2
6.1
MULTIPROP System
