Peri MULTIPROP Instructions For Assembly And Use page 2

Overview
Main components
1 MULTIPROP MP
1.1 Outer tube
1.2 Inner tube
1.3 Securing hook
1.4 Adjusting collar
1.5 Pressure spring
1.6 Measuring tape
1.7 Rubbing plate
1.8 Base plate
1.9 Head plate
2 Frame MRK
2.1 Wedge Coupling C
2.2 Wedge Coupling D
2.3 Wedge
2.4 Adhesive label / Type
1
1.9
1.2
1.6
1.4
1.7
1.1
1.8
2.3
2.1
Instructions for Assembly and Use – Standard Configuration
1.5
1.3
2.4
MULTIPROP System
2.2
