Peri MULTIPROP Instructions For Assembly And Use page 47

MULTIPROP Single Props and System
Item no. Weight kg
027302 2,100 MULTIPROP Strap SRZ U100 – U140
For fixing Steel Walers SRZ and SRU, Profile U100
to U140 on MULTIPROP slab props.
129565 1,680 Brace Connector MPR
For connecting push-pull props to the MP-System.
107161 3,050 Compression Brace Head MP/SRU
As connecting element between MULTIPROP slab
props and Steel Waler SRU/SRZ.
Accessories
104031 0,462 Fitting Pin Ø 21 x 120
Cotter Pin 4/1, galv.
018060 0,030
111142 0,082 MULTIPROP Bolt with Nut
250
Complete with
1 pc. 027170 Pin Ø 16 x 42, galv.
1 pc. 018060 Cotter Pin 4/1, galv.
2 pc. 129560 Collar Pin Ø 12
2 pc. 127322 Cotter Pin 3, 2/2, galv.
67 133
Ø16x42
14
Note
Seperate design information on request.
Technical Data
Permissible load-bearing capacity 70 kN.
60 50
120 120
50
SW 24
45
