2-1: Midi Control - Yamaha TG500 Owner's Manual

[UTILITY/SELECT] -> 2: Controller -> [ENTER] -> [PAGE] -> 2-1: MIDI Control -> [ENTER]
The four parameters provided in this screen allow any MIDI control device num-
bers to be assigned to TG500 controllers 1, 2, 3, and 4 (MC1, MC2, MC3, and
MC4).
UTL CTRL MC (Mod.Whl.)
1:001 2:004 3:018 4:109
Controllers 1 ... 4
MIDI Controllers 1 ... 4
Range: 000 ... 119
controller numbers appear to the left of the colon in each parameter), then use
the [-1/NO] and [+1/YES] keys to assign the desired MIDI control change
number. Some controller numbers are assigned to specific control devices (see
list below), while others have no specific controller assignment. If a control
device is assigned to the selected MIDI control number, an abbreviation of the
device name appears in parentheses in the upper right corner of the display.
lation wheel on the keyboard connected to the TG500 to function as Controller
1 ("MC1").
UTILITY MODE / WAVE EDIT MODE / 2: Controller

2-1: MIDI CONTROL

Position the cursor at the controller number you want to assign (TG500
For example, set the controller 1 parameter to "001" if you want the modu-
2-1: MIDI CONTROL 223
