3-2-03: SCALE POINT

[PLAY MODE] -> VCE PLAY -> [EDIT/COMPARE] -> 3: Full Edit -> [ENTER] -> 3-2: AEG -> [ENTER]
-> [PAGE] -> 3-2-03: Scale Point -> [ENTER]
Level scaling produces natural level variations across the range of the keyboard
by allowing different level "offset" values to be applied to each of four "breakpoints"
set at appropriate keys.
VCE AMP Scal Point <BP1>
E 1 B 2 G 4 A 5
BP1 ... BP4 (Break points 1 ... 4)
Range: C-2 ... G8
Allows four separate amplitude envelope generator level-scaling breakpoints
to be set at any notes between C-2 and G8 for the selected element. The level
offsets for each breakpoint are set using the "Scale Offset" parameters in the
next screen.
No breakpoint can be set to a key lower than the breakpoint to its left.
VOICE EDIT MODE / 3: Full Edit. 3-2: AEG
BP1 BP2 BP2 BP4
3-2-03: SCALE POINT 115
