3-3-01: Parameter - Yamaha TG500 Owner's Manual

[PLAY MODE] -> VCE PLAY -> [EDIT/COMPARE] -> 3: Full Edit -> [ENTER] -> 3-3: Filter -> [ENTER]
-> [PAGE] -> 3-2-01: Parameter -> [ENTER]
The TG500 features a sophisticated digital filter system that can be used to shape
the timbre of the voice being edited in a number of ways. Changes in the response
and cutoff frequency can be used to define the basic timbre of the voice, while
EG-controlled filter sweeps can produce a virtually unlimited range of time-based
timbre variations.
Type (Filter type)

3-3-01: PARAMETER

VCE FLT Param <Type>
F
LP (22.43kHz)127 71é
Type
VCE FLT Param <Band>
-
è -- EG
Band Ctrl
Determines the type of filter response used.
The "THRU" (THROUGH) setting turns the filter OFF.
The "LPF" (Low Pass Filter) and "LP12" settings produces a filter response
that allows only frequencies below the cutoff frequency (See "Cutoff" below) to
pass. The "LPF" filter type has a steep 24-dB/octave cutoff slope, while the
"LP12" type has a gentler 12-dB/octave slope.
VOICE EDIT MODE / 3: Full Edit. 3-3: Filter
Res
Cof
3-3-01: PARAMETER 119
