VOICE EDIT MODE / 1: Quick Edit
[PLAY MODE] -> VCE PLAY -> [EDIT/COMPARE] -> 1: Quick Edit -> [ENTER] -> [PAGE]
-> 1-2 : AEG -> [ENTER]
tude EG parameters, these parameters let you select from a range of preset envelope
types, and then modify the overall attack, sustain, and release characteristics as re-
quired.
Type (Envelope type)

1-2: AMPLITUDE EG

98
1-2: AMPLITUDE EG
Rather than having to set numerous level and rate values via the full-edit ampli-
For full amplitude EG parameters see page 111.
VCE QED AEG <Type >
1
0 :Piano é
Type
VCE QED AEG <AtkRate>
6
è 3 0 27 +3
SusLvl
AtkRate
Range: 00 ... 21
Selects either the envelope defined by the current amplitude envelope pa-
rameter settings (page 111), or one of 21 preset amplitude envelope types for
the current voice. The envelope types are:
Quick Edit Envelope Types
Vel
RlsRate
