The pinout is listed in the following table and printed on the back of the Power Panel. The Power Panel has reverse
polarity protection that prevents the supply voltage from being connected incorrectly and damaging the device.
Overload protection must be provided by an external fuse (5 A, fast-acting).
Terminal
1
2
Required accessories
0TB6102.2010-01
0TB6102.2110-01
Important!
The ground potential (which has a spade terminal) must be connected to ground (e.g. control cabinet)
using the shortest possible path.
Power Panel C-Series User's Manual V1.00
Pinout
+
-
Accessory terminal block, 2-pin (3.81), screw clamp 1.5 mm²
Accessory terminal block, 2-pin (3.81), cage clamp, 1.5 mm²
Table 45: Power supply
Power Panel C-Series • C-Series
Assignment
24 VDC
GND
