Power Panel C-Series • C-Series
Product ID
Dimensions
Width
Height
Depth
Table 29: 4PPC70.101G-21W, 4PPC70.101G-21B, 4PPC70.101N-21W, 4PPC70.101N-21B - Technical data
1)
The real-time clock is buffered for approx. 1000 hours @ 25°C by a gold foil capacitor. The gold foil capacitor is completely charged after 18 continuous
hours of operation.
2)
Shortest cycle time that is suitable for average applications. In certain cases, it is also possible to use shorter cycle times. The limit for the setting is specified
in the entry for the shortest task class cycle time.
3)
See the POWERLINK help system under "General information, Hardware - IF/LS".
4)
At an ambient temperature of 25°C.
5)
Remote stations connected via X2X Link, CAN bus, POWERLINK and Ethernet. Both USB interfaces are used.
54
4PPC70.101G-21W
4PPC70.101G-21B
276 mm
172 mm
4PPC70.101N-21W
172 mm
276 mm
51 mm
Power Panel C-Series User's Manual V1.00
4PPC70.101N-21B
