B&R Power Panel C Series User Manual page 21

Product ID
IF3 interface
Type
Design
Current load
IF4 interface
Type
Design
Current load
IF5 interface
Type
IF6 interface
Type
Design
Max. distance
Max. transfer rate
Bus length ≤25 m
Bus length ≤60 m
Bus length ≤200 m
Bus length ≤1000 m
IF7 interface
Type
Design
Max. distance
Max. transfer rate
Bus length ≤25 m
Bus length ≤60 m
Bus length ≤200 m
Bus length ≤1000 m
Display
Type
Display size
Colors
Resolution
Contrast
Viewing angles
Horizontal
Vertical
Backlight
Type
Brightness
Half-brightness time
4)
Touch screen
Type
Technology
Controller
Transmittance
Screen rotation
Electrical characteristics
Nominal voltage
Max. power consumption
5)
Reverse polarity protection
Electrical isolation
Operating conditions
Installation at elevations above sea
level
0 to 2000 m
>2000 m
EN 60529 protection
Environmental conditions
Temperature
Operation
Horizontal installation
Vertical installation
Storage
Transport
Relative humidity
Operation
Storage
Transport
Mechanical characteristics
Note
Front
Design
Table 13: 4PPC70.0573-21W, 4PPC70.0573-21B, 4PPC70.057L-21W, 4PPC70.057L-21B - Technical data
Power Panel C-Series User's Manual V1.00
4PPC70.0573-21W 4PPC70.0573-21B
VGA, 640 x 480 pixels
Reduction of ambient temperature by 0.5°C per 100 m
Order 1x 0TB5104.2110-01, 1x 0TB5106.2110-01, 1x
0TB6102.2010-01 and 1x 0TB6102.2110-01 terminal block separately
Aluminum white pinstripe Anthracite gray pinstripe
Power Panel C-Series • C-Series
4PPC70.057L-21W
USB 2.0
Type A
0.49 A
USB 2.0
Type A
0.10 A
X2X Link master
CAN bus
3 pins of the 6-pin multipoint connector
1000 m
1 Mbit/s
500 kbit/s
250 kbit/s
50 kbit/s
CAN bus
3 pins of the 6-pin multipoint connector
1000 m
1 Mbit/s
500 kbit/s
250 kbit/s
50 kbit/s
Color TFT
5.7"
262,000
Typ. 850:1
Direction R / Direction L = typ. 80°
Direction U / Direction D = typ. 80°
LED
Typ. 400 cd/m²
50,000 h
AMT
Analog resistive
B&R, serial, 12-bit
80% ±3%
Yes, using VC
24 VDC -15% / +20%
14.4 W
Yes
No
No limitations
Back: IP20
Front: IP65
0 to 50°C
0 to 50°C
-20 to 60°C
-20 to 60°C
See humidity diagram
See humidity diagram
See humidity diagram
Aluminum white pinstripe
4PPC70.057L-21B
VGA, 480 x 640 pixels
Anthracite gray pinstripe
21
