2.4.7.7 4PPC70.xxxx-23x - 1 CAN bus interface / 1 RS485 interface
1 2 3
Terminal
1
2
3
4
5
6
Required accessories
0TB5106.2110-01
2.4.7.8 Power supply
70
4 5 6
Figure 14: 4PPC70.xxxx-23x - 1 CAN bus interface / 1 RS485 interface
DATA
GND
DATA\
CAN_H
GND
CAN_L
Accessory terminal block, 6-pin (2.5), cage clamp, 0.5 mm
Table 44: 4PPC70.xxxx-23x - 1 CAN bus interface / 1 RS485 interface
Figure 15: Power supply
Pinout
RS485
Data
Ground
Data inverted
CAN bus
CAN_High
Ground
CAN_Low
