2.4.7.6 4PPC70.xxxx-22x - 1 CAN bus interface / 1 RS232 interface
1 2 3
Figure 13: 4PPC70.xxxx-22x - 1 CAN bus interface / 1 RS232 interface
Terminal
1
2
3
4
5
6
Required accessories
0TB5106.2110-01
Table 43: 4PPC70.xxxx-22x - 1 CAN bus interface / 1 RS232 interface
Power Panel C-Series User's Manual V1.00
4 5
6
TxD
GND
RxD
CAN bus
CAN_H
GND
CAN_L
Accessory terminal block, 6-pin (2.5), cage clamp, 0.5 mm
Power Panel C-Series • C-Series
Pinout
RS232
Transmit signal
Ground
Receive signal
CAN_High
Ground
CAN_Low
2
69
