2.4.7.4 X2X Link interface
Terminal
1
2
3
4
Required accessories
0TB5104.2110-01
Power Panel C-Series User's Manual V1.00
Figure 11: X2X Link interface
Pinout
X2X
X2X⊥
X2X\
SHLD
Accessory terminal block, 4-pin (2.5), cage clamp, 0.5 mm
Table 41: X2X Link interface
Power Panel C-Series • C-Series
X2X Link
X2X data
X2X ground
X2X data inverted
Shield
