2.4.7.5 4PPC70.xxxx-21x - 2 CAN bus
1 2 3
Terminal
1
2
3
4
5
6
Required accessories
0TB5106.2110-01
68
4 5
6
Figure 12: 4PPC70.xxxx-21x - 2 CAN bus
CAN_H
GND
CAN_L
CAN_H
GND
CAN_L
Accessory terminal block, 6-pin (2.5), cage clamp, 0.5 mm
Table 42: 4PPC70.xxxx-21x - 2 CAN bus
Pinout
CAN bus
CAN_High
Ground
CAN_Low
CAN_High
Ground
CAN_Low
2
Power Panel C-Series User's Manual V1.00
