Dahua Technology DHI-ITC952-RF2D User Manual page 68

Parameter Description
Insert
Front
Insert
Back
Modify
Delete
Remove
All
New Line
Step 7 Click Yes to save the configuration. You can right-click on the halo zone to delete the
zone.
Step 8 Click OK to save the configuration. Click Refresh to refersh the interface. Click Default
to restore to default settings.
6.5.1.5.3 Merge OSD
It is to configure the OSD information and location of composite picture.
Select Setting > ITC > OSD Config > Merge OSD. The Merge OSD interface is displayed.
See Figure 6-64.
The setting of Merge OSD is similar to Snap OSD. See "6.5.1.5.2 Snap OSD".
Select an OSD option, and then click Insert Front before selecting another
OSD option, the new OSD option will be shown before the original OSD option.
Select an OSD option, and then click Insert Back before selecting another
OSD option, the new OSD option will be shown after the original OSD option.
Click Modify, and the status of OSD information (New Line excluded) will
change to . Click
of corresponding OSD option.
Click Delete, and the status of all selected OSD information will change to
Click to delete the corresponding OSD option.
Delete all the OSD information.
Select one OSD information, and then click New Line. The option next to the
selected OSD information will be shown in a new line in the snapshot (captured
by clicking ANPR Receive on Live interface).
Figure 6-64
to modify the prefix, postfix, content and separater
Merge OSD
Web Configuration 61
.
