- Page 1 Smart ANPR Camera User's Manual V1.0.0...
-
Page 2: Foreword
Foreword General The manual introduces the structure and installation of the smart camera with access automatic number plate recognition (hereinafter referred to as "the camera"). Safety Instructions The following signal words might appear in the manual. Signal Words Meaning Indicates a high potential hazard which, if not avoided, will result in death or serious injury. - Page 3 format) cannot be opened. ● All trademarks, registered trademarks and company names in the manual are properties of their respective owners. ● Please visit our website, contact the supplier or customer service if any problems occur while using the device. ●...
-
Page 4: Important Safeguards And Warnings
Important Safeguards and Warnings This section introduces content covering the proper handling of the device, hazard prevention, and prevention of property damage. Read carefully before using the device, comply with the guidelines when using it, and keep the manual safe for future reference. Transportation Requirements Transport the device under allowed humidity and temperature conditions. - Page 5 liquid on the device to prevent liquid from flowing into it. ● Do not disassemble the device. ● Do not aim the device at strong light sources (such as lamplight, and sunlight) when focusing it. ● Do not vibrate, squeeze or immerse the device in liquid during transportation, storage or installation.
-
Page 6: Table Of Contents
Table of Contents Foreword ........................................I Important Safeguards and Warnings ............................III 1 Introduction ......................................1 1.1 Overview ......................................1 1.2 Features ......................................1 2 Structure ........................................3 2.1 Dimensions ....................................3 2.2 Entire Device ....................................3 2.3 Rear Panel ...................................... 4 2.4 Cable ........................................ -
Page 7: Introduction
1 Introduction 1.1 Overview The camera adopts intelligent deep learning algorithm. It supports vehicle detection, license plate recognition, logo recognition, model recognition, and color recognition, and encoding mode such as H.265. The camera consists of protective housing, illuminator, and intelligent HD camera. The intelligent HD camera adopts progressive scanning CMOS, which owns several features such as high definition, low illuminance, high frame rate, and excellent color rendition. - Page 8 Network Monitoring ● Transmits video data of single channel compressed by device to network terminal, and make it reappear after decompression through network. Keep delay within 500ms when bandwidth is allowed. ● Supports maximum 10 users online at the same time. ●...
-
Page 9: Structure
2 Structure 2.1 Dimensions Figure 2-1 Dimensions (mm [inch]) 2.2 Entire Device Figure 2-2 Entire device structure Table 2-1 Structure description Description Description Protective cover Illuminator Lens —... -
Page 10: Rear Panel
2.3 Rear Panel Figure 2-3 Bottom panel structure Table 2-2 Bottom panel description Description Description Slot for an SD card Debugging port Hardware reset — 2.4 Cable Figure 2-4 Cables Table 2-3 Cable description Function Description AUDIO OUT The camera sends out audio signal through this port. Alarm output, connecting to barrier, and alarm output devices Alarm out such as alarm light. - Page 11 Function Description RS-485 Connects to displays and other external devices. Wiegand Connects and sends number plates to access controller. Connects to a network. It also supports PoE power supply. Connects to 12 VDC power supply. 12 VDC Device damage will occur if power is not supplied correctly.
-
Page 12: Installation
3 Installation The following installation figures are for reference only, and might differ from the actual product. 3.1 Pole Mount Procedure Step 1 Fix the pole mount bracket to the pole. Step 2 Use 3 M6 screws to fix the junction box to the pole mount bracket. Step 3 Tighten the screws on the end of the camera to fix it to the junction box. -
Page 13: Ceiling Mount
Figure 3-2 Wall mount 3.3 Ceiling Mount Procedure Step 1 Drill holes on the ceiling according to the holes on the junction box. Step 2 Use 3 ST6.3 expansion screws to fix the junction box to the ceiling. Step 3 Tighten the screws on the end of the camera to fix it to the junction box. -
Page 14: Appendix 1 Cybersecurity Recommendations
Appendix 1 Cybersecurity Recommendations Mandatory actions to be taken for basic device network security: 1. Use Strong Passwords Please refer to the following suggestions to set passwords: ● The length should not be less than 8 characters. ● Include at least two types of characters; character types include upper and lower case letters, numbers and symbols. - Page 15 minimum set of permissions to them. 9. Disable Unnecessary Services and Choose Secure Modes If not needed, it is recommended to turn off some services such as SNMP, SMTP, UPnP, etc., to reduce risks. If necessary, it is highly recommended that you use safe modes, including but not limited to the following services: ●...
