Summary of Contents for Dahua Technology NKB1000
- Page 1 Keyboard Overview Solution Operation...
- Page 2 Keyboard Overview...
- Page 3 Overview - Appearance LCD Display Panel Common Area DVR Area PTZ Camera Area Joystick LED Indicator...
- Page 4 Overview - Interface NKB1000 KBD1000 KB1000...
- Page 5 Solution...
- Page 6 Keyboard to controls PTZ cameras keyboard controls max. PTZ cameras. RS485 Connection … All 3 models 2048 keyboard controls max. PTZ cameras. Network Connection Network … NKB1000 only...
- Page 7 Keyboard to controls DVR/NVR keyboard controls max. DVR/NVR. RS232 Connection NKB/KBD1000 only 2048 keyboard controls max. DVR/NVRs. Network Connection Network NKB1000 only...
- Page 8 Keyboard to controls DVR/NVR keyboard controls max. DVR/NVRs. RS485-RS232 Box All 3 models 1 keyboard 32 RS485-RS232 boxes, 1 RS485-RS232 box 12 RS232 connections...
- Page 9 Keyboard to controls SmartPSS keyboard controls max. USB to SmartPSS NKB1000 only...
- Page 10 Commonly Used Operations...
- Page 11 Adding devices to keyboard Zones “zone” list zone Tips: Every device that needs to be controlled by keyboard must be added as a “ ” first.
- Page 12 Menu of Keyboard This menu is for configuring the network for the keyboard (NKB1000 only). This menu is for adding a device (zone) to the keyboard control list. This menu is for controlling the device after you added the device to the keyboard.
- Page 13 Adding Zones After you’ve entered the “zone” menu. You’ll see the following parts: ID: This is the id of zones, you can set any number between 0~2048. Name: This is the name of zones, you can set any name with characters and digital numbers. Type: This is the type, you can choose DVR, NVR, SD, etc.
- Page 14 Commonly Used Operations … Control PTZ Camera (HDCVI/Analog/IP) Network …...
- Page 15 Link: COM485 485Addr: 100 Rule: PELCOD BaudRate: 9600 Note: you can set any ID or Name, but should set other parts based on the actual DataBit: 8 configuration of the PTZ camera. Parity: None RS485connection is available for NKB1000/KBD1000/KB1000. StopBit: 1...
- Page 16 Type: SD Link: NET IPAddr: 10.15.7.3 Port: 37777 Rule: DH-2 Note: you can set any ID or Name, but should set other parts based PW: qwerty on the actual settings of the PTZ camera. Network connection is only available for NKB1000.
- Page 17 Controlling PTZ Cameras After you’ve added the PTZ camera to the “zone” list of the keyboard. Enter the “Zone Control” menu, input the ID of the PTZ camera, click “ENTER”, the keyboard will connect to the PTZ camera and show the following interface. You can also choose other ways to connect: name, address, etc.
- Page 18 Controlling PTZ Cameras - Operation OTHER: Speed dome OSD menu PRESET: Set/call preset SCAN: Set/call scan PAN: Call pan TOUR: Set/call tour PATTERN: Set/call pattern Pan/Tilt/Zoom IRIS: control the aperture FOCUS: control the focus ZOOM: zoom in/out...
- Page 19 Commonly Used Operations Control DVR/NVRs Network...
- Page 20 Controlling DVR/NVRs – Via Network - Setup Network Connect the keyboard and the DVR/NVR to the same network.
- Page 21 Controlling DVR/NVRs – Via Network - Setup Check the IP address and the port number of the DVR/NVR.
- Page 22 Controlling DVR/NVRs – Via Network - Setup ID: 1 Name: MyDVR Type: NVR Link: NET IPAddr: 10.15.6.108 Add the DVR/NVR as a “zone” in the keyboard. Port: 37777 Rule: DH-2 PW: admin...
- Page 23 Controlling DVR/NVRs – Via RS232 - Setup Connect RS232 cable directly from keyboard to DVR/NVR.
- Page 24 Controlling DVR/NVRs – Via RS232 - Setup Check the address of the DVR/NVR in its menu.
- Page 25 Controlling DVR/NVRs – Via RS232 - Setup Check the RS232 configuration of the DVR/NVR.
- Page 26 Controlling DVR/NVRs – Via RS232 - Setup ID: 1 Name: MyDVR Type: DVR Link: COM232 Add the DVR/NVR as a “zone” in the keyboard. 232Addr: 8 Rule: DH-2 BaudRate: 9600 DataBit: 8 Parity: None StopBit: 1...
- Page 27 Connecting DVR/NVR After you’ve added the DVR/NVR to the “zone” list of the keyboard. Enter the “Zone Control” menu, input the ID of the DVR/NVR, click “ENTER”, the keyboard will connect to the DVR/NVR.
- Page 28 Operation Joystick up/down: switch among different display layout, such as 1/4/6/8/9/16/25 split, etc.
- Page 29 Operation Joystick left/right: switch cameras under current display spit. e.g. : When it’s display 1-4 channels in 4-split, move the joystick right direction will display 5-8 channels in 4-split.
- Page 30 Operation NUM + MULT: change different split. e.g. : 8+MULT will change the DVR/NVR to 8 split.
- Page 31 Operation NUM + CAM: choose specific channel to display in full- screen mode. e.g. : 1+CAM will put channel 1 in full-screen.
- Page 32 Operation NUM + PTZ: control PTZ for specific channel. e.g. : suppose channel 5 of DVR/NVR is connected to a PTZ camera, then 5+PTZ will put the camera in full-screen mode and you can use the joystick to control PTZ operations, also to see the OSD menu, set preset, tour and etc.
- Page 33 Operation For more specific operations on DVR/NVR, please refer to the user’s manual of NKB1000/KBD1000/KB1000.
- Page 34 Commonly Used Operations Control SmartPSS...
- Page 35 Controlling SmartPSS via USB After connecting NKB1000 to the PC, start SmartPSS software, it will detect the keyboard automatically.
- Page 36 Controlling SmartPSS via USB When adding devices in SmartPSS, click the keyboard icon, you can edit the number of all channels. You can use this number to Step 2 quickly switch between different cameras. Step 1...
- Page 37 Controlling SmartPSS via USB - Preview NUM + MULT: choose specific screen layout, e.g., 8 + MULT choose 8 split display.
- Page 38 Controlling SmartPSS via USB - Preview “8+MULT”...
- Page 39 Controlling SmartPSS via USB - Preview NUM + ID: choose specific window, e.g., 3 + ID choose the 3 window. You can also use the joystick to choose a window.
- Page 40 Controlling SmartPSS via USB - Preview “3+ID”...
- Page 41 Controlling SmartPSS via USB - Preview NUM + CAM: choose specific camera to display in current selected window. ENTER: switch current window between full screen and current display mode.
- Page 42 Controlling SmartPSS via USB - Preview “1+CAM” “ENTER” Click “ENTER” again...
- Page 43 Controlling SmartPSS via USB - Preview PTZ: if current window is displaying video from a PTZ camera, use this key to enter PTZ control for it.
- Page 44 Controlling SmartPSS via USB - Preview OTHER: Speed dome OSD menu PRESET: Set/call preset SCAN: Set/call scan PAN: Call pan TOUR: Set/call tour PATTERN: Set/call pattern Pan/Tilt/Zoom IRIS: control the aperture FOCUS: control the focus ZOOM: zoom in/out...
