G-force page

This page utilizes the LX
minimal G-loading during a ight, both numerically and graphically. The page also shows the
IAS sliding tape, TAS, altitude sliding tape and QNH, as depicted on the Thermal assistant page.
Your current G-load is shown graphically with a red dot.
Pressing the right push-rotary knob will open the 'G-force options' sub-page, where you can
reset the Min. and Max. values to zero.
Rotating the left push-rotary knob will change the scale of the G-force circles.
G corresponds to the average acceleration of the Earth's gravity eld on it's
It is important to note, that the LX
depicted by Fig.
is experiencing an acceleration of G in the X axis the LX
Device manual
k's internal inertial platform for showing the current, maximum and
Figure . G-force page overview
NOTE
surface, or 9, 81m/s .
NOTE
k shows accelerations in the Y-Z plane, as
., meaning no longitudinal accelerations are shown. If the plane
