LX
k
Device setup
Figure
. Four indicators on a white back-
ground theme
The following digital numerical indicators are available:
• Empty
• UTC time
• Local time
• Flight time
• Altitude
• IGC altitude
• Flight level
• Density altitude
• Alt. QNH [ft]
• Vario
• Vario AVG
• Vario netto
• Vario relative
• TAS
• IAS
• Ground speed
Since most of the indicators are self-explanatory, we will cover the ones that are not.
IGC altitude - altitude displayed by the internal IGC pressure sensor, which is not offset by
QNH changes.
Density altitude - the density altitude is the altitude relative to standard atmospheric conditions
at which the air density would be equal to the indicated air density at the place of observation.
Vario AVG - average vario calculated by integration according to given settings (the same
navbox is shown also on Thermal assistant page - AVG).
Device manual
Figure 6. Two indicators on a black back-
ground theme
• True track
• Distance Tp
• Distance Apt
• Distance Tsk
• Distance Nrst
• Final glide Tp
• Final glide Apt
• Final glide Tsk
• Final glide Nrst
• Bearing Tp
• Bearing Apt
• Bearing Tsk
• Bearing Nrst
• Speed to y
• Task time elapsed
• Task time left
Public
Document name:
Document revision:
• Current ef ciency
• Req. ef ciency Tp
• Req. ef ciency Apt
• Req. ef ciency Tsk
• Req. ef ciency Nrst
• Thermal max
• Thermal average
• Eff. thermal avg.
• Thermal gain
• Circling radius
• OAT
• ENL
• G-force
• Flap position
• Rec. ap position
